Engine Pro Performance Camshafts MC22396

Engine Pro Performance Camshafts MC22396 Specifications

• Mech (Mechanical)/Hyd (Hydraulic): Mech
• Stage: 4
• Dur @ .050" Int Exh: 242 242
• Adv. Dur. Int Exh: 310 297
• Valve Lift Int Exh: .508 .496
• Lobe Sep Int Exh: 108 120
• Power Range: 3200-7000
• Idle: Lash .020 Int .024 Exh Very Rough
• Lifter Part#: 992
• Notes: N
• Comments: Street Strip, 9.5:1 Compression, 3000 Stall Convertor Or Stick, Lower Gears -Gm #3904362

Legend for Notes

D -MAY REQUIRE CONVERSION TO AN ADJUSTABLE VALVE TRAIN., N - NOT COMPUTER COMPATIBLE

Applies to:

• Chevrolet Big Block V8 1967-95 396, 402, 427, 454 C.I. / 1969-90 366 C.I. (Chain Drive) Hydraulic Flat Tappet Cams

Description:

Street or strip, Engine Pro Performance Camshafts simply out perform the competition. Our manufacturing accuracy promotes improved valve train stability resulting in improved power gain. Our "controlled ramp" lobe profiles offer acceleration rates extending valve train life while delivering maximum horsepower.

• Ground in the U.S.A. 100% American Made Castings and Billets
• Manganese Phosphate Coated, Flame Hardened Castings or Induction Hardened Billets
• Computer Designed Lobe Profiles for Maximum Power
• Profiles are Adcole Verified for the Ultimate in Accuracy
• Journal Roundness Maintained to Within .0002"
