Engine Pro Performance Camshafts MC24305

Engine Pro Performance Camshafts MC24305 Specifications

• Mech (Mechanical)/Hyd (Hydraulic): Hyd
• Stage: 4
• Dur @ .050" Int Exh: 227 234
• Adv. Dur. Int Exh: 298 302
• Valve Lift Int Exh: .520 .520
• Lobe Sep Int Exh: 107 117
• Power Range: 2200-5400
• Idle: Rough
• Lifter Part#: 900
• Notes: N
• Comments: Good Street Performance With 2500 Stall Convertor, Good Torque

Legend for Notes

E -BASE CIRCLE SIZE OF CAMSHAFT IS SMALLER THAN STOCK SIZE. SPECIAL PUSH RODS OR ROCKER ARMS MAY BE REQUIRED TO KEEP GEOMETRY CORRECT AND AVOID DAMAGE., G -THE BASE CIRCLE SIZE OF THE CAMSHAFT MAY REQUIRE CONVERSION TO AN ADJUSTABLE VALVE TRAIN., N - NOT COMPUTER COMPATIBLE

Applies to:

• Ford V8 1962-91 221, 255, 260, 289, 302 C.I. (Except 1982-85 302 H.O. & 302 C.I. W/Hyd Roller Lifters) Firing Order 1-5-4-2-6-3-7-8 Hydraulic Flat Tappet Cams

Description:

Street or strip, Engine Pro Performance Camshafts simply out perform the competition. Our manufacturing accuracy promotes improved valve train stability resulting in improved power gain. Our "controlled ramp" lobe profiles offer acceleration rates extending valve train life while delivering maximum horsepower.

• Ground in the U.S.A. 100% American Made Castings and Billets
• Manganese Phosphate Coated, Flame Hardened Castings or Induction Hardened Billets
• Computer Designed Lobe Profiles for Maximum Power
• Profiles are Adcole Verified for the Ultimate in Accuracy
• Journal Roundness Maintained to Within .0002"
