Engine Pro Performance H-Beam Connecting Rods 10-1109-8
Engine Pro Performance H-Beam Connecting Rods 10-1109-8
Engine Pro Performance H-Beam Connecting Rods 10-1109-8 Specifications
- Length: 5.400
- Rod Journal Size: 2.123
- Pin Bore: .913
- Weight: 604
- Max Hp: 1100
ARP2000®:
An exclusive, hybrid-alloy developed to deliver superior strength and better fatigue properties. While 8740 and ARP2000 share similar characteristics ARP2000 is capable of achieving clamp loads in the 215,000-220,000 PSI range. ARP2000 is used widely in short track and drag racing as an up-grade from 8740 chrome moly in both steel and aluminum rods. Stress corrosion and hydrogen embrittlement are typically not a problem, providing care is taken during installation.
Applies to:
- Ford Small Block
Description:
Engine Pro H-Beam Connecting Rods are forged from 4340 steel. All of our rods are magnafluxed, heat treated, stress relieved, shot peened, and sonic tested to ensure they provide the strength required for high horsepower applications. All rods are produced on CNC machinery and are finished in the USA to ensure precise big end and pin end bore sizes. We weight match all of our sets of rods to + or -1.5 grams to make balancing easier. Silicon bronze bushings are installed for use with floating pins. Bolt lube and torque specifications are included. Engine Pro rods equipped with ARP's standard 8740 bolt are rated for up to 700 horsepower in small blocks, and 850 horsepower in big block applications.
- Magnafluxed
- Forged from 4340 steel
- Three levels of bolts - ARP 8740 cap screw, ARP 2000, ARP L19
- Heat treated
- Stress relieved
- Shot peened
- Bronze bushed pin bores
- Weight balanced + or - 1.5 grams
- ARP moly bolt lube included
