Engine Pro Performance Nitro Black Beehive Springs 02-1200-16

Engine Pro Performance Nitro Black Beehive Springs 02-1200-16 Specifications

• Spring O.D. Bottom: 1.061
• Spring I.D. Bottom: 0.737
• Spring O.D. Top: 0.960
• Spring I.D. Top: 0.636
• Closed Height: 1.640
• Closed Load: 80
• Open Height: 1.090
• Open Load: 185
• Coil Bind: 1.020
• Max. Lift: .550
• Rate: 191
• Material Type (Cr, Si, V, Ni: Chrome, Silicon, Vanadium, Nickel): Cr-Si-V-Ni
• Steel Retainer Number: 03-1012
• Titanium Retainer Number: n/a

Applies to:

Description:

• Beehive shaped design allows a reduced retainer end mass for improved rpm potential
• Every spring goes through a multiple shot peening process to ensure maximum durability and stress relief
• Heat Set" process and special heat treatment are used to extend spring life and minimize load loss
• Ovate wire shape more evenly distributes mass throughout the wire cross section
