Engine Pro Performance Nitro Black Beehive Springs 02-1203-16

Engine Pro Performance Nitro Black Beehive Springs 02-1203-16 Specifications

• Spring O.D. Bottom: 1.412
• Spring I.D. Bottom: 1.065
• Spring O.D. Top: 1.000
• Spring I.D. Top: 0.650
• Closed Height: 1.750
• Closed Load: 123
• Open Height: 1.175
• Open Load: 284
• Coil Bind: 1.100
• Max. Lift: .650
• Rate: Cr-Si-V-Ni
• Material Type (Cr, Si, V, Ni: Chrome, Silicon, Vanadium, Nickel): N/A
• Steel Retainer Number: n/a
• Titanium Retainer Number: n/a

Applies to:

Description:

• Beehive shaped design allows a reduced retainer end mass for improved rpm potential
• Every spring goes through a multiple shot peening process to ensure maximum durability and stress relief
• Heat Set" process and special heat treatment are used to extend spring life and minimize load loss
• Ovate wire shape more evenly distributes mass throughout the wire cross section
