Engine Pro Performance Nitro Black Beehive Springs 02-1204-16

Engine Pro Performance Nitro Black Beehive Springs 02-1204-16 Specifications

• Spring O.D. Bottom: 1.292
• Spring I.D. Bottom: 0.880
• Spring O.D. Top: 1.062
• Spring I.D. Top: 0.650
• Closed Height: 1.800
• Closed Load: 105
• Open Height: 1.200
• Open Load: 298
• Coil Bind: 1.100
• Max. Lift: .625
• Rate: 322
• Material Type (Cr, Si, V, Ni: Chrome, Silicon, Vanadium, Nickel): Cr-Si-V-Ni
• Steel Retainer Number: 03-1011, 03-1013, 03-1014, 03-1015
• Titanium Retainer Number: 03-1794

Applies to:

Description:

• Beehive shaped design allows a reduced retainer end mass for improved rpm potential
• Every spring goes through a multiple shot peening process to ensure maximum durability and stress relief
• Heat Set" process and special heat treatment are used to extend spring life and minimize load loss
• Ovate wire shape more evenly distributes mass throughout the wire cross section
