Engine Pro Performance

Engine Pro Performance Nitro Black Beehive Springs 02-1205-16

Engine Pro Performance Nitro Black Beehive Springs 02-1205-16

Regular price $127.40 USD
Regular price Sale price $127.40 USD
Sale Sold out
Shipping calculated at checkout.

Engine Pro Performance Nitro Black Beehive Springs 02-1205-16 Specifications

  • Spring O.D. Bottom: 1.237
  • Spring I.D. Bottom: 0.825
  • Spring O.D. Top: 1.062
  • Spring I.D. Top: 0.650
  • Closed Height: 1.700
  • Closed Load: 110
  • Open Height: 1.175
  • Open Load: 292
  • Coil Bind: 1.115
  • Max. Lift: .575
  • Rate: 347
  • Material Type (Cr, Si, V, Ni: Chrome, Silicon, Vanadium, Nickel): Cr-Si-V-Ni
  • Steel Retainer Number: 03-1011, 03-1013, 03-1014, 03-1015
  • Titanium Retainer Number: 03-1794

Applies to:

Description:

  • Beehive shaped design allows a reduced retainer end mass for improved rpm potential
  • Every spring goes through a multiple shot peening process to ensure maximum durability and stress relief
  • Heat Set" process and special heat treatment are used to extend spring life and minimize load loss
  • Ovate wire shape more evenly distributes mass throughout the wire cross section
